Product Description
Welding Hastelloy Bar C-22 UNS N06022 W.Nr.2.4602 Suitable For Environments With Alternating Oxidizing And Reducing Conditions
Welding Hastelloy C-22 (UNS N06022, W.Nr. 2.4602) nuts requires careful control due to its high corrosion resistance and nickel-based composition. The material is highly resistant to oxidizing and reducing environments, making it ideal for chemical processing and marine applications. Gas Tungsten Arc Welding (GTAW/TIG) is preferred, using ERNiCrMo-10 filler metal for best compatibility. Proper shielding gas, such as argon or helium, prevents oxidation. Preheating is not required, but interpass temperatures should be kept below 93°C (200°F) to avoid carbide precipitation. Post-weld treatments are generally unnecessary, though solution annealing can restore corrosion resistance. Cleanliness is critical to prevent contamination. Proper technique ensures strong, defect-free welds, maintaining the nut’s mechanical properties and corrosion resistance.
Chemical Composition Wt.% % Ni Cr Fe C Mn Si Mo V P S Co W
Min Bal. 20 2 12.5 2.5
Max Bal. 22.5 6 0.015 0.5 0.08 14.5 0.35 0.02 0.02 2.5 3.5
Physical Constants Density(g/cm³) 8.9
Melting Range(℃) 1325-1370
Minimum mechanical properties of alloy at room temperature Typical mechanical properties Tensile strength Rm N/mm² Yield strength RP 0.2 N/mm² Elongation A5 %
Solution treatment 690 283 40
Welding Hastelloy C-22 (UNS N06022, W.Nr. 2.4602) nuts requires special considerations due to the alloy's unique properties. Here are the key features to keep in mind:
1. Material Composition & Properties
High Corrosion Resistance: Excellent resistance to oxidizing and reducing environments, making it ideal for harsh chemical processing applications.
Nickel-Based Alloy: Contains Nickel (~56%), Chromium (~22%), Molybdenum (~13%), Iron (~3%), and small amounts of Cobalt, Tungsten, and others.
Low Carbon Content: Minimizes carbide precipitation and intergranular corrosion.
2. Welding Considerations
Filler Material: Use ERNiCrMo-10 (AWS A5.14) or a similar nickel-based filler wire to match the alloy’s corrosion resistance.
Preheating & Post-Weld Treatment:
No preheating is required.
Post-weld heat treatment is usually unnecessary but can be considered in highly corrosive environments.
Shielding Gas: Use pure argon or an argon-helium mix for GTAW (TIG) welding.
Heat Input Control: Maintain low heat input to prevent grain growth and maintain mechanical properties.
3. Common Welding Processes
GTAW (TIG): Preferred method for precise and clean welding of small components like nuts.
GMAW (MIG): Can be used but requires careful heat control.
PAW (Plasma Arc Welding): Used for automated and high-precision applications.
4. Challenges & Precautions
Avoid Contamination: Clean surfaces thoroughly to prevent contamination from iron, sulfur, or other elements.
Cracking Resistance: Hastelloy C-22 has good resistance to hot cracking but still requires careful weld bead placement.
Weld Oxidation Control: Back purging with argon helps prevent oxidation in root passes
Applications:
Welding Hastelloy C-22 (UNS N06022, W.Nr. 2.4602) nuts or components requires careful consideration due to its high corrosion resistance, especially against pitting, crevice corrosion, and stress corrosion cracking. Here’s a detailed guide to welding applications for Hastelloy C-22 nuts:
1. Welding Considerations
Filler Material: Use ERNiCrMo-10 (AWS A5.14) or ENiCrMo-10 (AWS A5.11) filler metal.
Welding Process: Preferable methods include:
GTAW (TIG) – Best for precise and clean welds.
GMAW (MIG) – Used when speed is a priority.
SMAW (Stick Welding) – Suitable for field applications.
PAW (Plasma Arc Welding) – Used for high-quality fusion.
Preheat & Post-Weld: No preheating is required, and post-weld heat treatment (PWHT) is usually not necessary, but stress relief annealing at 1100–1200°F (593–649°C) can be done if needed.
Interpass Temperature: Maintain below 200°F (93°C) to prevent grain growth and sensitization.
2. Nut Application Welding
Tack Weld Carefully: Avoid excessive heat input, which can cause distortion.
Controlled Heat Input: Keep the heat input low to prevent carbide precipitation.
Shielding Gas: Use pure argon or argon-helium mixtures to protect the weld pool.
Back Purging: Recommended when welding critical applications to maintain corrosion resistance inside the nut.
Cleaning: Remove oxides and contaminants before welding using mechanical or chemical cleaning.
3. Applications of Hastelloy C-22 Nuts
Chemical Processing: Used in reactors, heat exchangers, and piping systems where extreme corrosion resistance is required.
Marine & Offshore: Ideal for saltwater environments and harsh offshore conditions.
Aerospace: Used in components that face extreme temperatures and corrosive environments.
Pharmaceutical & Food Processing: Preferred due to high purity and resistance to contamination.
Power Generation: Suitable for high-temperature and acidic environments in scrubbers and heat recovery systems.
