Elongation rate
线径(mm) | 伸长率(Lo=200mm),% Elongation rate( Lo=200mm),% |
≤0.05 | 6 |
>0.05~0.10 | 8 |
>0.10~0.50 | 12 |
>0.50 | 15 |
Thermal EMF rate for copper
合金名称 Name | 合金牌号 Type | 温度范围℃ Temperature range | 对铜平均热电动势率, uV/C Average thermal EMF rate for copper |
锰铜Manganin | 6J12 | 0~100 | 1 |
F1锰铜F1Manganin | 6J8 | 0~100 | 2 |
F2锰铜F2Manganin | 6J13 | 0~100 | 2 |
康铜 Constantan | 6J40 | 0~100 | 45 |
注：对铜热电动势率为绝对值。Note: Thermal EMF rate for copper is absolute value. | |||
The net weight per spool
标称直径 Dia.(mm) | 净质量 （g） | 标称直径 Dia.(mm) | 净质量 （g） |
0.02~0.025 | 5 | >0.28~0.45 | 300 |
>0.025~0.03 | 10 | >0.45~0.63 | 400 |
>0.03~0.04 | 15 | >0.63~0.75 | 700 |
>0.04~0.06 | 30 | >0.75~1.18 | 1200 |
>0.06~0.08 | 60 | >1.18~2.50 | 2000 |
>0.08~0.15 | 80 | >2.50 | 3000 |
>0.15~0.28 | 150 |
