TYPE | CuNi1 NC003 | CuNi2 NC005 | CuNi6 NC010 | CuNi8 NC012 | CuMn3 MC012 | CuNi10 NC015 | CuNi14 NC020 | CuNi19 NC025 | CuNi23 NC030 | CuN30 NC035 | CuNi34 NC040 | CuNi44 NC050 | |
Composition (%) | Cu | Rest | Rest | Rest | Rest | Rest | Rest | Rest | Rest | Rest | Rest | Rest | Rest |
Mn | -- | -- | -- | -- | 3 | -- | 0.3 | 0.5 | 0.5 | 1.0 | 1.0 | 1.0 | |
Ni | 1 | 2 | 6 | 8 | 10 | 14.2 | 19 | 23 | 30 | 34 | 44 | ||
Max.continuous operating temperature ℃ | 200 | 200 | 220 | 250 | 200 | 250 | 300 | 300 | 300 | 350 | 350 | 400 | |
Nominal value μO·m（20℃） | 0.03±10% | 0.05±10% | 0.1±10% | 0.12±10% | 0.12±10% | 0.15±10% | 0.2±5% | 0.25±5% | 0.3±5% | 0.35±5% | 0.4±5% | 0.49±5% | |
Resistance-temperature coefficient×10ˉ6/℃ （20-600℃） | <100 | <120 | <60 | <57 | <38 | <50 | <38 | <25 | <16 | <10 | -0 | <-6 | |
Thermovoltage to copper at 20℃in μV/K | -8 | -12 | -18 | -22 | 1 | -25 | -28 | -32 | -34 | -37 | -39 | -43 | |
Mean coefficient of linear thermal expansion, in 10ˉ6/k, at a temperature between20℃ and 400℃ | 17.5 | 17.5 | 17.5 | 17.5 | 18 | 17.5 | 17.5 | 17.5 | 17.5 | 17.0 | 16.0 | 15.0 | |
Thermal conductance at 20℃ W/mK | 145 | 130 | 92 | 75 | 84 | 59 | 48 | 38 | 33 | 27 | 25 | 23 | |
Specific heat capacity at 20℃ in 20℃ J/gK | 0.38 | 0.38 | 0.38 | 0.38 | 0.39 | 0.38 | 0.38 | 0.38 | 0.38 | 0.39 | 0.40 | 0.41 | |
Density at 20℃(g/cm3) | 8.9 | 8.9 | 8.9 | 8.9 | 8.8 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | |
Melting temperature in℃ | 1085 | 1090 | 1095 | 1097 | 1050 | 1100 | 1115 | 1135 | 1150 | 1170 | 1180 | 1280 | |
Min. tensile strength in N/mm² | 210 | 220 | 250 | 270 | 290 | 290 | 310 | 340 | 350 | 400 | 400 | 420 | |
Elongation% | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
